EP Equipment EPL185 Powered Pallet Truck, 1800kg

PRODUCT

With a 48V system and 0.9kw drive motor, the EPL185 is designed for medium-heavy duty pallet handling applications requiring lots of power! This all-electric pallet truck has a pull out lithium ion battery and a fast recharging time of only 2 hours. It is ideal for busy applications invoving the handling of heavy pallets, as well as ramps and slopes. The floating steel battery cartridge protects it against weather conditions and external impacts. Small size is another feature, with a low own weight of only 170kg and a length behind the forks of only 400mm. Floating castors wheels provide excellent stability and a high quality programmable Curtis speed controller allows the truck to be set to the individual requirements of the user and environment.

APPLICATION

The EPL185 is a good choice for busy or multi-shift medium to heavy duty pallet handling applications. It is particularly useful on delivery vehicles, lorry tail lifts and in applications where pallets must be moved up ramps & slopes: it can move a 1 ton pallet up a 10% gradient with no operator effort required. All-electric lift, lower and drive, this powerful truck moves heavy pallets of up to 1.8 tons.

An alternative 1500kg version is available for lighter duty applications with smaller pallet weights, slopes & gradients.

FEATURES

Replacing a hand pallet truck with an electric pallet truck eliminates operator pushing and pulling of heavy loads. It prevents staff injuries and sickness associated with manual handling. The EPL185 comes with an electromagnetic braking system, for greater safety when working on ramps, slopes, or on a lorry tail lift.

Key Features

Nothing to show

EP Equipment EPL185 Powered Pallet Truck, 1800kg

Technical Data
Unit
Info
Model
EP Equipment EPL185
Operator Type
Pedestrian
Lift Type
Electric
Load Capacity
Kg
1800
Net Weight (including battery)
Kg
170
Dimensions
Unit
Info
Lowered Height (Forks)
mm
80
Lift Height
mm
195
Fork Span
mm
540 / 685
Fork Length
mm
1150
Individual Fork Width
mm
150
Overall Width
mm
610 / 695
Overall Length
mm
1550
Turning Radius
Wa mm
1330
Aisle width (Euro Pallet: 800 x 1200)
mm
2050
Wheels
Unit
Info
Fork Roller Material
Polyurethane
Drive Wheel Material
Polyurethane
Drive & Performance
Unit
Info
Drive Motor Power (Kw)
kw
0.9
Travel Speed, loaded/unloaded (Km/h)
Km/h
5 / 5.5
Max Gradeability on slopes, loaded / unloaded
%
6 / 16
Battery Voltage/Capacity A/h
V / A/h
48 / 20
Battery Type
Maintenance Free Lithium
Charger Internal or External / Rating
Internal
Lift Motor Rating
Kw
0.8
Lift Speed with/without load
m/ s
0.020 / 0.025
Lowering Speed with/without load
m/ s
0.065 / 0.030
