Logitrans HSS Inox EX, ATEX Explosion Proof Straddle Stacker Truck, 1000kg

The HSS Inox EX is an exceptionally high quality stainless steel stacker truck with straddle support legs, from Danish manufacturer Logitrans. It is designed for hazardous areas, where an explosive atmosphere is occasionally generated due to gases or dust. Straddle stackers are useful for handling closed based pallets (eg UK Chep pallets). Unlike a stacker with wrapover support legs, a straddle stacker can lift via sides where bottom runners are present.

Customise your HSS Inox EX: alternative fork spans, fork lengths and leg lengths are available, for handling non standard sizes, IBC containers, box pallets, crates, cages, stillages and dolavs. This stacker can be built with other attachments (eg drum turnerboom spearcrane arm) for handling non-palletised goods and items such as Euro bins & tote bins. It can be customised with special features for bespoke handling applications. Please contact us to discuss your requirement.

The design focuses on the safety and ergonomic working conditions of the user. High quality is ensured through an extended test programme and in co-operation with experts in health and safety.

Suitable for lifting closed and open sided pallets, with or without bottom boards. If you are handling open based pallets only (eg EUR pallets), then an alternative ATEX explosion proof stainless steel pallet stacker is available.

Other explosion proof pallet trucks are also available: please see Panther Inox EX hand pallet truck & HL Inox Plus EX scissor lifter.

Features:

Key Features

Nothing to show

Technical Data
Unit
Info
Model
Logitrans HSSI 1000 EX
Operator Type
Pedestrian
Lift Type
Manual
Load Capacity
Kg
1000
Dimensions
Unit
Info
Lowered Height (Forks)
mm
65
Lift Height
mm
1170 / 1370 / 1570 / 2020 / 2420
Fork Span
mm
Adjustable 350 - 800
Fork Length
mm
1150
Individual Fork Width
mm
163
Load Centre
mm
max 600
Overall Length
mm
1650 (1150mm forks)
Overall Mast Height (Lowered / Lifted)
mm
Internal Straddle Width + 225
Length without forks
mm
435
Width between Straddle Legs
mm
435 - 1250 (not adjustable)
Wheels
Unit
Info
Fork Roller Material
White Nylon
Steering Wheel Material
Antistatic
Drive & Performance
Unit
Info
Lift Speed with/without load
m/ s
normal/quick 17/54 per pump
Lowering Speed with/without load
m/ s
0.21

More Images

Scroll along the images to see more

Logitrans HSS Inox EX

ATEX Explosion Proof Straddle Stacker

  • Exceptional quality ATEX explosion proof straddle stacker truck
  • Categorised in equipment group II, suitable for zone 1/21 hazardous areas
  • Straddle support legs for closed based pallets, crates, cages & IBCs
  • Available with special fork and support leg sizes, for non standard applications
  • 2 year warranty
Awaiting videos, please check back soon
